CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge

China CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier
CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge supplier

Large Image :  CM-8821 0~1000 um / 0~40 mil Magnetic Induction F Type Coating Thickness Gauge

Product Details:

Place of Origin: China
Certification: CE ,Rohs
Model Number: GS-CM8826FN

Payment & Shipping Terms:

Minimum Order Quantity: 10pcs
Packaging Details: in color box
Delivery Time: 3-5 days for sample order or according to your order quantity
Payment Terms: Paypal ,West Union,T/T, MoneyGram
Supply Ability: 10000 pcs/month
Contact Now
Detailed Product Description
Measuring Range: 0~1000 Um / 0~40 Mil Min. Measuring Area: 6 Mm
Resolution: 0.1 Um / 1 Um Min. Sample Thickness: 0.3 Mm
Accuracy: ± 1~3%n Or ± 2.5 Um

Specification :




Operating Principle Magnetic Induction ( F )
Measuring Range 0~1000 um / 0~40 mil
Resolution 0.1 um / 1 um
Min. Radius Workpiece F Type: convex 1.5 mm / concave 25 mm
Min. Measuring Area 6 mm
Min. Sample Thickness 0.3 mm
Accuracy ± 1~3%n or ± 2.5 um
Auto Power Off
Metric / Imperial Convertible
Battery Indicator Low Battery Indicator
Operating Conditions Temp. 0~40 °C, Humidity: 10~90 %RH
Power Supply 4 x 1.5 V AA (UM-3) Battery
Dimensions 161 x 69 x 32 mm
Weight 210 g (Not Including Batteries)



Standard Accessories:



1. Main Unit

2. Probe ( F Type )

3. Calibration Base Set ( F Type ) CTG-BS

4. Calibration Foils CTG-CF (1 set, 4 pieces)

5. Carrying Case

6. Operation Manual



Application :



Coating thickness gauge are used for measuring thickness and corrosion of pressure vessels,chemical equipment,boilers,oil storage tanks,etc.in industries of petroleum,shipbuilding,power station,and machine manufacturing.
