Max Sampling Rate: | 500MSa/S | Bandwidth: | 50MHz |
---|---|---|---|
Vertical Resolution: | 8bit | Vertical Accuracy: | +/- 3% |
Impedance: | 1MΩ 25pF | Coupling: | DC\AC |
Specification :
Max Samples Rate :500MSa/S
Channel: 2CH
Bandwidth: 50MHz
Vertical resolution: 8
Input range: 10mV - 100mV - 5V; x1 50V; X10 1V 500V; X100 (1,2,5 step)
Vertical accuracy of ±3%:
Impedance: 1M Omega 25pF
Coupling: DCAC
Display mode: YT
Input voltage: 40V (x1); 400V (X10); 4000V (X100)
Time base range: 10ns-50ms (step 1,2,5) 100ms-5s (Scan scan)
Storage depth: 16K
Trigger mode: automatic, normal, single
Trigger type: the rise, decline
Automatic detection of:50Hz-60MHz
Measurements: the peak to peak, duty cycle, frequency, cycle
Cursor: time, voltage
Screen:4.3 inch 16 bit true color TFT 400*272
Signal generator:
Frequency of: 0Hz - 20MHz
Duty cycle of: 0% - 100&
Amplitude of:100mV - 4V
Offset:±0V - 2V
Serial center:
Baud rate of:115200 - 1200
Data bits:8, 9
Check:NO, ODD, EVEN
Stop bit:1, 0.5, 2, 1.5
Hex: 10, 16
Recorder:
Base: 100ms - 5S
Diode: 0V ~ 2.0V
On-off: in 600 ohm position detection, sound less than 30 Omega
Maximum resolution: 6000
