GM61 Handheld Precise CCTV Network Cable Tester Telephone Wire Tracker Line Finder Inspection Instrument
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Display: | 2.0 Inches TFT LCD Screen | Signal Transmission Distance: | ≥1km |
|---|---|---|---|
| Environmental Operating Temperature: | -10 ~ 40℃ (14 ~ 104°F) | Relative Humidity: | 10-95% RH |
CCTV tester is a practical product that integrates video and wires searching function, used in camera installation and debugging and metal conductor wires search. Widely used in camera installation, telephone lines and other wires search.
Features:
PAL NTSN standard automatic identification;
Low battery indication;
Volume adjustment ;
Headphone jack output;
Video monitoring;
Charging;
Specification:
Hunt signal transmission distance:> 1Km
Display: 2.0 inches TFT LCD screen
Automatic shutdown: Under video status, 8 minutes without any operation of automatic shutdown
Environmental Operating Temperature: -10 ~ 40℃ (14 ~ 104°F)
Relative humidity: 10-95% RH
Storage temperature: -20 ~ 60℃ (-4 ~ 140°F)
Size
Transmitter: 64 * 31 * 118.9mm
Receiver: 48.6 * 26 * 117mm
TEU Quantity: 20PCS
Standard box size: 52.9 * 34.9 * 28.5cm
Weight
Transmitter: 68.8g
Receiver: 59.2g
Power supply
Transmitter: 3 * 3.7V lithium battery
Receiver: 6F22 9V battery
Caution :
Do not use the cable order verifying function for the cable that have electricity.
Take out the batteries if the products are not expected to be used for a long time to avoid the erosion of battery leakage which may result in poor battey contact.
Do not dismantle the device , if there are any quality problem ,please contact us to solve the problem.
Warning :
Tracing the cable with strong current may result in personal injuries and/or equipment damage.
Use the unit in thunder storm weather may result in personal injuries and/or equipment damage.
